Hockey field lighting system design
2020 factory made led hockey field light with high quality led stadium light anti glare led high mast light with 30 year lifespan
We need proper hockey field lighting to be played at night.The size of the hockey field is about 91 x 55 meters, and it lights up such a large area that we usually use high-powered outdoor stadium lights with up to 1,000 to 2,000 watts of power.In addition to sufficient brightness, the best hockey field lighting systems should be glare resistant and flicker-free to improve the vision of players and spectators.Let’s take a look at lighting a hockey stadium or club with LED, and the lighting effects of using LED instead of metal halides, HPS, and mercury vapor lamps.
Hockey field lighting design
Unlike other commercial lighting, stadium lighting is more challenging because we need to solve more problems.The first is brightness.
Pls check the blew link to see the more detail information about Cricket ground light:
1.Lux level of the hockey field lighting
Usually, the brightness level increases with the standard of the game.Lux levels are about 200 to 300 lux for recreational or community hockey club play.It takes between 500 and 750 lux to compete nationally.If the field of hockey is designed to host an international tournament, such as the Men’s and women’s Champions League, Commonwealth Games or World Cup, we need to have a horizontal illumination of up to 1000-2000 Lux.
Pls check the blew link to see the product detail information:
We need to consider both horizontal and vertical lighting.Horizontal lighting refers to the brightness of the ground, while vertical lighting refers to hockey players’ faces and bodies.Vertical illumination level is a basic parameter for FHD or 4K TV broadcasting because it allows the camera to clearly capture the movement of the athlete.
Pls check the blew link to see the more detail information about football field light:
The challenge was to maintain a comparable ratio of horizontal and vertical illumination at 1:1.Our lighting designers will provide the best divisor lighting plan for different needs.We customize the lights as appropriate as we understand that each project has its own unique pole placement and lighting requirements.Please feel free to leave a comment for free lighting advice.
2.Uniformity
Due to the limitations of lamp posts and lighting fixtures, there are usually bright spots and dark spots in reality.But if it was important enough until after the hockey player’s performance, that would be unbearable.
Lighting uniformity is measured from 0 to 1 (maximum).It is the ratio between the minimum illumination and the average illumination or between the minimum illumination and the maximum illumination on the ground.The lighting uniformity required for professional competitions is about 0.7.We offer quality lighting solutions with lighting uniformity of 0.7 to 0.8.
Pls check the blew link to see the product detail information:
3.Avoid Flicker
The visible strobe makes the eyes of players and spectators tense.It also affects video recording.The flicker problem is especially serious if you use fluorescent lamps, metal halides, or other gas discharge lighting devices.To provide better lighting for the hockey rink, we developed flicker-free LED lights that support high-speed cameras up to 5,000 to 6,000 Hz to capture fast-moving hockey puck and hockey sticks.Let’s take a look at our demo.
4.Reduce light pollution by using anti-glare mirrors
Sometimes we use up to 5,000 to 20,000 watts of LED lights on the hockey field.Improper optical devices will lead to severe light pollution in the surrounding area.It affects not only the quality of life of the people living nearby, but also the wildlife around them.We use a patented lens cap that concentrates light to a specified area, reducing & GT;Ninety-three percent of light leaks.
The advantages of USING LED lights in the field hockey field
If you are wondering whether to use LED stadium lights or replace your existing HID lights.Let’s explore the advantages of using LED stadium lights.
Pls check the blew link to see the more detail information about baseball field light:
1.Higher durability
One of the biggest incentives is that we can enjoy more durable lighting by switching to LED.LED last 10 times longer than halogen bulbs.We can save the cost of buying a new lamp and the installation cost of each replacement.Our LED sports lights have a service life of up to 80,000 hours or over 30 years.
In addition, LED have a better IP rating and are therefore more durable.Our LED stadium light have The function of IP66, so they are suitable for outdoor high mast lighting.It operates normally during storms and other adverse weather conditions.
2.More energy efficiency
LED use less energy to provide the same lumen brightness.Did you know that different types of lighting have their own luminescence (energy efficiency)? Our LED stadium lights are 130 to 140 lumens per watt, compared with 10 to 15 lumens per watt for halogen bulbs and 75 to 90 lumens per watt for metal halides.
The investment is worthwhile because it brings many long-term benefits, although the initial cost is slightly higher than conventional lighting.
3.Greater flexibility
As we have our own r&d team and factory, we can customize LED stadium lights according to different needs.For example, after obtaining ground illumination and uniformity requirements, rod height, rod number and other basic information from customers, we will provide tailor-made lighting solutions (with different structural designs, power, beam angles, lenses, drivers, etc.) that are best suited to your situation.
Pls check the blew link to see the more detail information about rugby field light:
If you have a project requiring stadium lighting system configuration for more information, please contact us with details and feel free to email us at [email protected].
