Stadium Lights Renovation Guide Tip (Replacing with LED Lights)
Energy saving stadium light with high lumen efficiency anti glare football field lights manufacture led sport lighting selling cost
Advantages of stadium lights transformation with LED stadium lights
1.Use LED stadium lights instead of metal halide lights
LED stadium lights provide better lighting quality than halide lamps. It has the following advantages:
- No warm-up time
- More energy saving (lower wattage)
- No cooldown time
- Save operation and maintenance costs
2.Replace mercury vapor bulbs with LED stadium lights
Mercury vapor can easily escape from broken bulbs, which is very dangerous. Inhalation of mercury vapor can cause acute poisoning. Permanent damage to the nervous system, even death.
LED stadium lights prevent any adverse consequences of using mercury vapor bulbs.
- LED lights do not contain mercury
- The LED lights don’t flash, so you don’t need to replace them
- Mercury vapor bulbs emit ultraviolet radiation, while LED do
3.Use LEDstadiumlights instead of high pressure sodium lamps
The CRI of HPS lamp is relatively low, generally < 60. But LED stadium lights with a color rendering index of 90, are more suitable for FIFA World Cup matches.
HPS lights give off a lot of heat. And LED stadium lights have a good heat dissipation system. HPS lamp has the shortest life among all HID lamps.
How to use LED stadium lights to replace metal halide lights?
1.Lumens of MH
Before replacing the metal halide lights with LED stadium lights, it is necessary to know how many lumens the MH bulbs emit. Usually the model name of the stadium lights is printed on the base of the light. Use this name or code to find the initial lumen value. We can look for LED stadium lights that can replace metal halide lights
2.Common wattage of LED stadium lights in place of metal halide lights
If you can’t find lumen values, here are some common wattages to help you find the equivalent LED stadium lights.
- 300W LED stadium light is typically 48,000 lumens
- 500W LED stadium light is typically 80,000 lumens
- 600W LED stadium light is typically 96,000 lumens
- 1000W LED stadium light is typically 160,000 lumens
- 1200W LED stadium light is typically 192,000 lumens
- 1800W LED stadium light is typically 288,000 lumens
Most LED stadium lights can save you at least a third on your electric bill. Generally 300 watt LED stadium lights can replace 1000 watt metal halide lights. Over time, lumens of halide lamps decrease.
If it is to replace the new 1000 watts HM with LED stadium lights. You will see a slight increase in the wattage of LED stadium lights.
MH light sources have a light efficiency of 50-80 lumens per watt. LED stadium lights have an efficiency of 150 lumens per watt.
3.Adapt to LED stadium lights can choose the precise beam Angle
Using LED stadium lights you can choose the exact beam Angle. You can choose between a wide beam Angle (120 or higher) or a narrow beam Angle (less than 60). LED stadium lights offer remote control, and you can even use your smartphone to control each light body on most models.
4.Note the input voltage difference when refitting old MH lamps
Note the input voltage difference when refitting old MH lamps with LED stadium lights. MH lights require a ballast to work, while LED stadium lights do not.
How to replace mercury steam lights with LED stadium lights?
1.Lumens of mercury vapor lamps
Because mercury vapor light efficiency is low, below 60 lumens per watt, frequent replacement is required. A standard 1,000-watt mercury vapor lamp can produce up to 58,000 lumens.
After 5,000 hours, its lumen output drops significantly. So almost any LED stadium light will do. Even the cheapest 500-watt LED spotlights provide 6,600 lumens.
2.Common wattage of LED stadium lights in place of mercury vapor lamps
Mercury vapor lamps are usually replaced with LED stadium lights with at least half the wattage. If you can’t calculate the lumen output of an old mercury vapor lamp. Please check the screw base, it will show the wattage. Replacing a 2,000 watt mercury vapor lamp requires almost 1,000 watts of LED stadium lights.
3.Color temperature selection
Stadium mercury vapor lamps emit blue light. In technical terms, it’s called color temperature. Use LED stadium lights to select cold white light with a color temperature higher than 5500K. Most sports lighting requirements, such as FIFA’s, recommend not using a color temperature above 7000K.
How to use LED stadium lights instead of HPS?
1.Lumens of HPS
HPS lamps provide satisfactory illumination in most areas. Most commercial 1000 watt high pressure sodium lamps have lumens between 110000 and 130000. Since the advent of LED lamps, most manufacturers have stopped producing HPS bulbs with higher wattage.
2.Common wattage of LED stadium lights replacing HPS
LED stadium light technology often exceeds HPS light technology. The new generation of LED modifications provide a more reliable system for the sports industry. Usually 1000W HPS lights are replaced with 600W LED stadium lights. Better positioning is also possible due to lower heat emissions from LED stadium lights.
3.CRI(color rendering index)
Many disadvantages of HPS include a low color rendering index. You’d be hard-pressed to find an HPS lamp with a color rendering index of more than 40. CRI gives you an idea of what an illuminated object really looks like. The higher the CRI level, the better the lighting effect. For televised class matches, you will need to provide at least 90CRI of high-powered stadium lights. Therefore, it is necessary to replace the old HPS lights with efficient LED stadium lights.
4.Replacing HPS lights with LED stadium lights bypasses ballasts.
Before removing the high-pressure sodium lamps and replacing them with LED stadium lights, they need to be cooled and bypassed by the ballast. First, turn off the power. Most LED stadium lights allow you to bypass both ferromagnetic ballasts and igniters. Just cut the live and neutral lines and follow the manufacturer’s instructions Manual operation. In general, you only need to connect the input live wire and the null wire to their respective output lines.
Key points needing special attention when transforming stadium lights
1.power supply
You can’t just compare the wattage of old HID lights to new LED stadium lights. You need to view the lumen output of the new lamp and the old lamp. Looking at the lamp model is the fastest way to figure out the lumen output and choose the equivalent LED stadium light.
Most football field fixtures use 2000W LED stadium lights. Provide adequate levels of illumination for football matches. If you know the illumination level required for your stadium, you can work out the necessary lumen output for each LED stadium light retrofit.
2.Beam angle
Old lamps have specific beam angles. Therefore, new LED stadium lights should have the same or similar beam angles. In addition, the new DIALux lighting design is strongly recommended. In this way, it is easy to find the desired beam Angle and lumens.
DIALux is a well-known lighting design software that can help you achieve the best lighting results. Due to high energy consumption, every modern stadium needs to be renovated and installed, replacing those traditional lights with LED stadium lights.
By calculating the exact beam Angle of each light fixture, energy requirements can be further reduced. You can also save money on accessories. Mainly by selecting more products with specific beam angles.
3.Input voltage
LED stadium light refits absorb more energy when the input voltage is wrong. Higher voltages can cause the power supply and running wires in the lamp holder or adapter to overheat.
Since LED stadium lights are semiconductor resistors, voltage absorption will vary. This means it doesn’t matter if the replacement uses more or less wattage than the old HID lamp. You need to understand and provide the appropriate input voltage for the replacement to work properly.
4.The weight of LED stadium lights used to replace the old lamps
Some light poles may not be able to support the weight of the new LED stadium lights. So you need to check if the new LED stadium lights are too heavy.
Before you retrofit the entire stadium lighting system, just replace one HID lamp. Check light poles for any signs of tilt or deviation from vertical angles.
Most tall masts are placed a few feet or meters from the sideline. But falling fixtures still pose a safety hazard due to broken glass and the potential for fires in hot weather.
Conclusion
We have been a stadium lighting manufacturer for more than 10 years. If you want to replace those old traditional lights with LED stadium lights, please feel free to contact us via email [email protected], we will provide you with the design for free.
